msq_obtain_object_check 분석

static inline struct msg_queue *msq_obtain_object_check(struct ipc_namespace *ns, int id) { struct kern_ipc_perm *ipcp = ipc_obtain_object_check(&msg_ids(ns), id); if (IS_ERR(ipcp)) return ERR_CAST(ipcp); return container_of(ipcp, struct msg_queue, q_perm); }

#define IPC_MSG_IDS 1 #define msg_ids(ns) ((ns)->ids[IPC_MSG_IDS])

struct ipc_namespace { struct ipc_ids ids[3]; ... } struct ipc_ids { int in_use; unsigned short seq; struct rw_semaphore rwsem; struct idr ipcs_idr; int max_idx; int last_idx; /* For wrap around detection */ #ifdef CONFIG_CHECKPOINT_RESTORE int next_id; #endif struct rhashtable key_ht; };

struct kern_ipc_perm *ipcp = ipc_obtain_object_check(&msg_ids(ns), id);

/** * ipc_obtain_object_check * @ids: ipc identifier set * @id: ipc id to look for * * Similar to ipc_obtain_object_idr() but also checks the ipc object * sequence number. * * Call inside the RCU critical section. * The ipc object is *not* locked on exit. */ struct kern_ipc_perm *ipc_obtain_object_check(struct ipc_ids *ids, int id) { struct kern_ipc_perm *out = ipc_obtain_object_idr(ids, id); if (IS_ERR(out)) goto out; if (ipc_checkid(out, id)) return ERR_PTR(-EINVAL); out: return out; }

/** * ipc_obtain_object_idr * @ids: ipc identifier set * @id: ipc id to look for * * Look for an id in the ipc ids idr and return associated ipc object. * * Call inside the RCU critical section. * The ipc object is *not* locked on exit. */ struct kern_ipc_perm *ipc_obtain_object_idr(struct ipc_ids *ids, int id) { struct kern_ipc_perm *out; int idx = ipcid_to_idx(id); out = idr_find(&ids->ipcs_idr, idx); if (!out) return ERR_PTR(-EINVAL); return out; }

out = idr_find(&ids->ipcs_idr, idx);

struct idr { struct radix_tree_root idr_rt; unsigned int idr_base; unsigned int idr_next; };

/** * idr_find() - Return pointer for given ID. * @idr: IDR handle. * @id: Pointer ID. * * Looks up the pointer associated with this ID. A %NULL pointer may * indicate that @id is not allocated or that the %NULL pointer was * associated with this ID. * * This function can be called under rcu_read_lock(), given that the leaf * pointers lifetimes are correctly managed. * * Return: The pointer associated with this ID. */ void *idr_find(const struct idr *idr, unsigned long id) { return radix_tree_lookup(&idr->idr_rt, id - idr->idr_base); } EXPORT_SYMBOL_GPL(idr_find);

/** * radix_tree_lookup - perform lookup operation on a radix tree * @root: radix tree root * @index: index key * * Lookup the item at the position @index in the radix tree @root. * * This function can be called under rcu_read_lock, however the caller * must manage lifetimes of leaf nodes (eg. RCU may also be used to free * them safely). No RCU barriers are required to access or modify the * returned item, however. */ void *radix_tree_lookup(const struct radix_tree_root *root, unsigned long index) { return __radix_tree_lookup(root, index, NULL, NULL); } EXPORT_SYMBOL(radix_tree_lookup);

#define radix_tree_root xarray struct xarray { spinlock_t xa_lock; /* private: The rest of the data structure is not to be used directly. */ gfp_t xa_flags; void __rcu * xa_head; };

#define radix_tree_root xarray struct xarray { spinlock_t xa_lock; /* private: The rest of the data structure is not to be used directly. */ gfp_t xa_flags; void __rcu * xa_head; };

int radix_tree_insert(struct radix_tree_root *root, unsigned long index, void *item) { struct radix_tree_node *node; void __rcu **slot; int error; BUG_ON(radix_tree_is_internal_node(item)); error = __radix_tree_create(root, index, &node, &slot); if (error) return error; error = insert_entries(node, slot, item); if (error < 0) return error; if (node) { unsigned offset = get_slot_offset(node, slot); BUG_ON(tag_get(node, 0, offset)); BUG_ON(tag_get(node, 1, offset)); BUG_ON(tag_get(node, 2, offset)); } else { BUG_ON(root_tags_get(root)); } return 0; } EXPORT_SYMBOL(radix_tree_insert);

static int __radix_tree_create(struct radix_tree_root *root, unsigned long index, struct radix_tree_node **nodep, void __rcu ***slotp) { struct radix_tree_node *node = NULL, *child; void __rcu **slot = (void __rcu **)&root->xa_head; unsigned long maxindex; unsigned int shift, offset = 0; unsigned long max = index; gfp_t gfp = root_gfp_mask(root); shift = radix_tree_load_root(root, &child, &maxindex); /* Make sure the tree is high enough. */ if (max > maxindex) { int error = radix_tree_extend(root, gfp, max, shift); if (error < 0) return error; shift = error; child = rcu_dereference_raw(root->xa_head); } while (shift > 0) { shift -= RADIX_TREE_MAP_SHIFT; if (child == NULL) { /* Have to add a child node. */ child = radix_tree_node_alloc(gfp, node, root, shift, offset, 0, 0); if (!child) return -ENOMEM; rcu_assign_pointer(*slot, node_to_entry(child)); if (node) node->count++; } else if (!radix_tree_is_internal_node(child)) break; /* Go a level down */ node = entry_to_node(child); offset = radix_tree_descend(node, &child, index); slot = &node->slots[offset]; } if (nodep) *nodep = node; if (slotp) *slotp = slot; return 0; }

struct radix_tree_node *node = NULL, *child; slot = (void __rcu **)&root->xa_head; child = radix_tree_node_alloc(...); rcu_assign_pointer(*slot, node_to_entry(child));

static inline void *node_to_entry(void *ptr) { return (void *)((unsigned long)ptr | RADIX_TREE_INTERNAL_NODE); } root->xa_head = node_to_entry(child);

static struct radix_tree_node * radix_tree_node_alloc(gfp_t gfp_mask, struct radix_tree_node *parent, struct radix_tree_root *root, unsigned int shift, unsigned int offset, unsigned int count, unsigned int nr_values)

#define radix_tree_node xa_node struct xa_node { unsigned char shift; /* Bits remaining in each slot */ unsigned char offset; /* Slot offset in parent */ unsigned char count; /* Total entry count */ unsigned char nr_values; /* Value entry count */ struct xa_node __rcu *parent; /* NULL at top of tree */ struct xarray *array; /* The array we belong to */ union { struct list_head private_list; /* For tree user */ struct rcu_head rcu_head; /* Used when freeing node */ }; void __rcu *slots[XA_CHUNK_SIZE]; union { unsigned long tags[XA_MAX_MARKS][XA_MARK_LONGS]; unsigned long marks[XA_MAX_MARKS][XA_MARK_LONGS]; }; };

void *__radix_tree_lookup(const struct radix_tree_root *root, unsigned long index, struct radix_tree_node **nodep, void __rcu ***slotp) { struct radix_tree_node *node, *parent; unsigned long maxindex; void __rcu **slot; restart: parent = NULL; slot = (void __rcu **)&root->xa_head; radix_tree_load_root(root, &node, &maxindex); if (index > maxindex) return NULL; while (radix_tree_is_internal_node(node)) { unsigned offset; parent = entry_to_node(node); offset = radix_tree_descend(parent, &node, index); slot = parent->slots + offset; if (node == RADIX_TREE_RETRY) goto restart; if (parent->shift == 0) break; } if (nodep) *nodep = parent; if (slotp) *slotp = slot; return node; }

static inline struct msg_queue *msq_obtain_object_check(struct ipc_namespace *ns, int id) { struct kern_ipc_perm *ipcp = ipc_obtain_object_check(&msg_ids(ns), id); if (IS_ERR(ipcp)) return ERR_CAST(ipcp); return container_of(ipcp, struct msg_queue, q_perm); }

/** * container_of - cast a member of a structure out to the containing structure * @ptr: the pointer to the member. * @type: the type of the container struct this is embedded in. * @member: the name of the member within the struct. * * WARNING: any const qualifier of @ptr is lost. */ #define container_of(ptr, type, member) ({ \ void *__mptr = (void *)(ptr); \ static_assert(__same_type(*(ptr), ((type *)0)->member) || \ __same_type(*(ptr), void), \ "pointer type mismatch in container_of()"); \ ((type *)(__mptr - offsetof(type, member))); }) /**

struct msg_queue { struct kern_ipc_perm q_perm; time64_t q_stime; /* last msgsnd time */ time64_t q_rtime; /* last msgrcv time */ time64_t q_ctime; /* last change time */ unsigned long q_cbytes; /* current number of bytes on queue */ unsigned long q_qnum; /* number of messages in queue */ unsigned long q_qbytes; /* max number of bytes on queue */ struct pid *q_lspid; /* pid of last msgsnd */ struct pid *q_lrpid; /* last receive pid */ struct list_head q_messages; struct list_head q_receivers; struct list_head q_senders; } __randomize_layout;
